Viterra Motor
1 / 4
| Ratio | 241k |
| Max. Rated Torque | 1.5~2.0 Kgf.cm |
| Max. Gear Breaked Torque | 4~5 Kgf.cm |
| Gearbox Efficiency | 45%~60% |
| Model | Ratio | Voltage (V) | No-Load | Rated | Stall | ||||
| Speed (RPM) | Current (mA) | Speed (RPM) | Current (mA) | Torque (Kgf.cm) | Current (mA) | Torque (Kgf.cm) | |||
| GM2215FMN20-241K | 1 : 241 | 4.5 VDC | 43 | ≤ 50 | 34 | ≤ 120 | 2.5 | ≤ 350 | 1.5 |
| 58 | ≤ 65 | 50 | ≤ 130 | 2.8 | ≤ 680 | 1.8 | |||
| 68 | 75 | 56 | ≤ 140 | 3.0 | ≤ 750 | 2.0 | |||
| Motor Model | Voltage | No-Load Speed | Rated Torque | Stall Torque |
| SL-N20-04510500 | 4.5VDC | 10500 RPM | 2.0 gf.cm | 10.5 gf.cm |
| SL-N20-04514000 | 4.5VDC | 14000 RPM | 2.5 gf.cm | 15.0 gf.cm |
| SL-N20-04516500 | 4.5VDC | 16500 RPM | 2.5 gf.cm | 18.0 gf.cm |
Our factory specializes in motor production with over 14 years of experience. A professional R&D team and mature management system ensure a high-quality experience for every requirement.
Quality is the basis of our development. Every step, from material receipt to shipment, is carefully checked to ensure performance and durability.
