SRC-370SH-4730 Factory Hot Selling 4.5V 17500rmp 3.63A Output 11.51W

Send Inquiry

Product Description

High-performance factory hot selling motor featuring 4.5V input, 17500rmp speed, and 11.51W output power.

Product Description

Model	Rated Voltage (V)		No-Load		Rated				Stall
Model	Operating Range	Nominal	Speed (RPM)	Current (mA)	Speed (RPM)	Current (mA)	Torque (mN.m)	Power (W)	Current (mA)	Torque (mN.m)
RF-370CA-061700	6.0~24.0	24 VDC	1320	3	1000	8	0.98	0.1	260	4.02
RC-370CH-20123	3.0~6.0	6 VDC	8000	70	6878	420	2.4	1.71	2550	17
RC-370SH-4730	3.0~5.0	4.5 VDC	17500	550	15199	3630	7.2	11.51	24000	55
RC-370SH-18139	6.0~12.0	12 VDC	10000	130	8439	700	5.8	5.17	3800	37.5

Application & Versatility

Our PMDC motors are widely utilized in various industries and products ranging from security systems to household appliances.

Frequently Asked Questions

What is the rated voltage of the SRC-370SH-4730 motor?

The nominal rated voltage for the SRC-370SH-4730 model is 4.5 VDC, with an operating range typically between 3.0V and 5.0V.

What is the maximum output power of this series?

For the RC-370SH-4730 model, the rated output power reaches approximately 11.51W, providing high efficiency for its size.

What is the no-load speed for the 4.5V model?

The motor features a high-speed performance of 17500 RPM under no-load conditions at the nominal 4.5V voltage.

Can these motors be used in security systems?

Yes, these PMDC motors are ideal for security systems, micro-pumps, children's electric toys, and various small household appliances.

Are there other voltage versions available for the 370 series?

Yes, the series includes models designed for 6V, 12V, and 24V nominal operation to suit different power requirements.

What kind of torque does the RC-370SH-4730 provide?

It provides a rated torque of 7.2 mN.m (approx. 73.4 gf.cm) and a stall torque of up to 55 mN.m.
