Viterra Motor
1 / 5
Product Categories
Product Description
| PMDC MOTOR Technical Data | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Model | Rated Voltage (V) | No-Load | Rated | Stall | |||||||
| Operating Range | Nominal | Speed | Current | Speed | Current | Torque | Power | Current | Torque | ||
| RPM | mA | RPM | mA | mN.m / gf.cm | W | mA | mN.m / gf.cm | ||||
| FK-280SA | 4525 | 1.0~2.0 | 1.2VDC | 8670 | 730 | 6560 | 2240 | 1.74/17.7 | 1.3 | 8430 | 9.61/98 |
| 16245 | 6.0~12.0 | 12VDC | 7300 | 60 | 6027 | 290 | 3.4/34.6 | 2.15 | 1350 | 19.5/198 | |
Application Areas
Certifications
Why Choose Us
We are a factory specializing in producing motors for more than 14 years. With a professional R&D team, mature management, and experienced engineers, we ensure a high-quality production process.
In order to confirm quality, every step from raw material receipt to shipment is carefully checked. Quality is the foundation of our development.
• High credibility and 100% on-time delivery rate.
• Standard samples produced within 2 weeks.
• Customized samples produced within 3 weeks.
• Rapid response: messages replied within 2 hours.
