Viterra Motor
1 / 5
| PMDC MOTOR Technical Data | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Model | Rated Voltage (V) | No-Load | Rated | Stall | |||||||
| Operating Range | Nominal | Speed (RPM) | Current (A) | Speed (RPM) | Current (A) | Torque (mN.m) | Power (W) | Current (A) | Torque (mN.m) | ||
| RS-380SH | 4052 | 3.0~6.0 | 4.8VDC | 7800 | 0.32 | 6701 | 1.95 | 9.9 | 6.98 | 11.9 | 70.6 |
| 3557 | 6.0~12.0 | 12VDC | 21200 | 0.44 | 18367 | 2.85 | 11.26 | 21.68 | 18.5 | 84.3 | |
| RS-385SH | 17110 | 6.0~24.0 | 24VDC | 11000 | 0.15 | 9034 | 0.69 | 10.7 | 10.12 | 3.16 | 59.8 |
| 2267 | 6.0~12.0 | 12VDC | 10000 | 0.17 | 8340 | 0.85 | 7.5 | 6.53 | 4.29 | 45 | |
Our enterprise was established in 2005 as a high-tech company integrating research, development, production, and sales of various micro DC motors, geared motors, planetary geared motors, and specialized gearbox motors.
Our products are widely utilized in automotive systems, communication equipment, smart homes, medical devices, intelligent security, and household appliances. We export to over 50 countries and regions worldwide, providing high-end transmission solutions.
